Fisher费希尔1061型气动执行机34B4647X032

Fisher1061型气动指挥器旋转管道通风口轴直径50.8mm执行机构尺寸80,100改装套件34B4647X032

更多关于1061型执行机构详情请点击：Fisher产品主页

产品规格：

致动方式：双作用、直角回转、旋转

控制类型：开/关、节流

动力源：气动

阀门类型：球阀、蝶阀、偏心栓塞阀、三通偏移阀

1061型其他相关产品

执行机构维修套件                 维修套件(包含件号5,8, 16, 17,18, and 56)

尺寸30  R1061X00302                                                                   尺寸30 R1061X00302

尺寸40  R1061X00402                                                                   尺寸40 R1061X00402

尺寸60  R1061X00602                                                                   尺寸60 R1061X00602

尺寸68  R1061X00682                                                                   尺寸68 R1061X00682

尺寸80  R1061X00802

尺寸100 R1061X01002

管道通风口改装套件

轴直径            执行机构尺寸

12.7mm                30尺寸                     34B4646X022                        44.5mm                       40,60,68尺寸    34B4646X132

15.9mm                30尺寸      34B4646X032                        50.8mm                       40,60,68尺寸    34B4646X142

19.1mm                30尺寸     34B4646X042                        50.8mm                       80,100尺寸     34B4647X032

19.1mm                40,60,68尺寸   34B4646X052                       54.0mm                       80,100尺寸     34B4647X042

22.2mm                30尺寸     34B4646X062                       63.5mm      80,100尺寸     34B4647X052

22.2mm                40,60,68尺寸   34B4646X072

25.4mm                30尺寸     34B4646X082

25.4mm                40,60,68尺寸   34B4646X092

31.8mm                30尺寸     34B4646X102

31.8mm                40,60,68尺寸   34B4646X112

38.1mm                40,60,68尺寸   34B4646X122

69.9x63.5 to101.6x63.5 尺寸100       3484647X052
